Product Details
Ultra-Fast Temperature Transition
Accelerated Reliability Testing for High-Volum Industrial Applications
|Core Functionality
This chamber is engineered to achieve exceptionally rapid heating and cooling rates, dramatically shortening test cycle times compared to standard temperature chambers. This enables high-throughput Environmental Stress Screening (ESS), accelerated life testing, and efficient qualification of electronics, automotive components, and aerospace parts.
|Product Features
1. High-speed Thermal Cycling
Transition Rates: 5℃/min, 10℃/min, 15℃/min;
Temperature Range: -70℃ to +180℃(extendable with liquid nitrogen cooling);
Uniformity: ≤1.5℃ across all shelves;
Humidity Performance: 20% ~98%Rh(optional)
2. High-Capacity, Uniform Performance
With a generous 1000-liter workspace, it accommodates large or batch of samples.
Advanced air circulation and precise control systems ensure outstanding temperature uniformity and stability throughout the chamber, guaranteeing consistent and reliable test results for every item.
3. Energy Efficiency & Compliance
Cooling Technology: Advanced cooling control system reduces energy consumption;
Control System: Touchscreen PLC with real-time cures;
Safety Protection: Leakage/overload cutoff, automatic defrost;
Construction: SUS 304 stainless steel interior, anti-corrosion exterior;
Standards: IEC 60068, MIL-STD-810G
|Applications
Electronics: PCB/IC thermal validation, solder joint fatigue testing
Automotive: ECU durability, sensor performance under rapid transitions
Aerospace: MIL-STD-810G compliance for avionics and materials
|Parameters
Interior Dimension(mm) | 1250×800×1000 |
External Dimension(mm) | 1600×2100×1970 |
Heating/Cooling Rate | 5℃/min, 10℃/min, 15℃/min(Leaner) |
Temperature Range | -70℃ to +150℃(-70℃to 180℃ is available) |
Fast Temperature Range | -40℃ to 85℃ |
Humidity Range | 10~98%RH |
Temperature Deviation | ≤2℃ |
Temperature Fluctuation | ≤0.5℃ |
Cooling Way | Water-cooling |
Power | AC380V, 50Hz, 3Phase 5 wires |
|Why Choose 1000L Fast thermal cycling Chamber?
Fast Testing Cycles: Achieve rapid temperature transitions to shorten test time and accelerate product development.
Large 1,000L Capacity: Test high-volume batches or large assemblies efficiently in a single run.
Precise & Reliable: Ensures stable and uniform temperature control for consistent, dependable results.
Durable Construction: Built for demanding, continuous operation to ensure long-term reliability.
Easy to Use: Intuitive controls simplify setup and operation of complex test programs.
Optimize your testing efficiency. Contact us for a detailed specification sheet and custom quote.
